Shredder
Shredding machine
The mono shear type shredders utilize a multi toothed single rotor working against a fixed anvil, the scrap being forced in to the rotor by a controlled hydraulic pusher. This machine is characterized by lower energy consumption and quieter mode of operation.
Technical details
| Rotor shaft | Dia 300 mm having multiple tooth bolted at fixed in-terval |
| Width of the machine | 1500 mm (approx) |
| Gear box | In line gear box |
| Motor | 50 HP |
| Drive | Through fluid coupling via V belt drive |
| Structure | Heavy duty steel structure supported by joist |
| Hopper | Fabricated steel structure |
| Hydraulic power pack | 2 HP power pack for pushing operation |
| Capacity of the machine | 500 kg/hour ( UBC Baled scrap ) |
Other sizes are also available as per the requirement
